Brass Hinges


BRASS HINGES > 'L' TYPE BUTT HINGES : THICKNESS 2.3 mm. 2.5 mm.


Button Brass 'L' Type Butt Hinges Button Brass 'W' Type Hinges Button Brass Z Type Hinges
Button Brass Reflex Hinges Button Brass Ball Pivot Hinges Button Brass Ball Bearing Pivot Hinges
Button Brass Parliament Hinges Button Brass Door Closer Hinges Button Brass Duble Action Door Closer Hinges
Button Brass Rising Hinges Set



L type Butt Hinges

High performance brass ball catches with minimum 25 year performance.
Suitable for locking any type of wardrobes.

Maintenance free.

Standard Finish :

Button Self Colour
Button Polished & lacquered
Button Satin brass & lacquered
Button Satin chrome plated
Button Polished chrome plated
Button Satin nickel plated
Button Antique finish

Special finishes available upon request.



BRASS L TYPE BUTT HINGES : THICKNESS 2.3 mm. 2.5 mm.

CODE NO. SIZE IN INCH SIZE IN MM BARREL IN MM PIN DIA. MM
17-001 3" x 3/8" x1.1/4" 6mm. 76 x 9 x 31 x 2.3mm. 7.00 4.00
17-002 4" x 3/8" x1.1/4" 6mm. 101 x 9 x 31 x 2.3mm. 7.00 4.00
17-003 3" x 3/8" x1.1/4" 12mm. 76 x 9 x 31 x 2.3mm. 7.00 4.00
17-004 4" x 3/8" x1.1/4" 12mm. 101 x 9 x 31 x 2.3mm. 7.00 4.00
17-005 3" x 3/8" x1.1/4" 19mm. 76 x 9 x 31 x 2.3mm. 7.00 4.00
17-006 4" x 3/8" x1.1/4" 19mm. 101 x 9 x 31 x 2.3mm. 7.00 4.00
17-007 3" x 1/2" x1.1/2" 6mm. 76 x 9 x 38 x 2.3mm. 7.00 4.00
17-008 4" x 1/2" x1.1/2" 6mm. 101 x 9 x 38 x 2.3mm. 7.00 4.00
17-009 3" x 1/2" x1.1/2" 12mm. 76 x 9 x 381 x 2.3mm. 7.00 4.00
17-010 4" x 1/2" x1.1/2" 12mm. 101 x 9 x 38 x 2.3mm. 7.00 4.00
17-011 3" x 1/2" x1.1/2" 19mm. 76 x 9 x 38 x 2.3mm. 7.00 4.00
17-012 4" x 1/2" x1.1/2" 19mm. 101 x 9 x 38 x 2.3mm. 7.00 4.00
17-013 3" x 1/2" x1.1/2" 25mm. 76 x 9 x 38 x 2.3mm. 7.00 4.00
17-014 4" x 1/2" x1.1/2" 25mm. 101 x 9 x 38 x 2.3mm. 7.00 4.00
17-015 3" x 3/4" x1.3/4" 8mm. 76 x 9 x 44 x 2.3mm. 7.00 4.00
17-016 4" x 3/4" x1.3/4" 8mm. 101 x 9 x 44 x 2.3mm. 7.00 4.00
17-017 3" x 3/4" x1.3/4" 12mm. 76 x 9 x 44 x 2.3mm. 7.00 4.00
17-018 4" x 3/4" x1.3/4" 12mm. 101 x 9 x 44 x 2.3mm. 7.00 4.00
17-019 3" x 3/4" x1.3/4" 19mm. 76 x 9 x 44 x 2.3mm. 7.00 4.00
17-020 4" x 3/4" x1.3/4" 19mm. 101 x 9 x 44 x 2.3mm. 7.00 4.00
17-021 3" x 3/4" x1.3/4" 25mm. 76 x 9 x 44 x 2.3mm. 7.00 4.00
17-022 4" x 3/4" x1.3/4" 25mm. 101 x 9 x 44 x 2.3mm. 7.00 4.00
